GLOBALIND-B2292225

This compact step-down DC-DC converter has an input voltage of 24 VDC nominal (range 20 VDC to 37 VDC) to a highly regulated output voltage of 12 VDC nominal at 60 Amps. This a non-isolated 60 amp DC-DC converter and is made for use in negative ground systems. These units have CE EN61000-6-3:2007+A1:2011 and CE EN61000-6-1:2007 60 Amp 24 volt to 12 volt dc to dc converter Features: Green LED on front panel to confirm power on Terminal block for DC input/output Over Temperature protection Over Load protection DC Input Low Battery Shutdown DC Input High Battery Shutdown DC Output Short Protection DC Output Over Current Protection DC Output Over Voltage Protection Transformer based Aluminum case for optimal cooling Instruction manual Free 1 year tech support 1 Year Warranty Parts and Labor SPecifications: CE EN61000-6-3:2007+A1:2011 CE EN61000-6-1:2007 DC Input Voltage: 20-37 Vdc DC Output Voltage: 12.5-13.5 Vdc Output Current: 60 amps Output Current Max: 72 amps Non-Isolated Conversion Effiency: >90% DC Input Low Battery Shutdown: 18 +/- 1 V DC Input High Battery Shutdown: >38Vdc DC Input Over Current Protection: 30A Fuse DC Input Polarity Protection: Fuse Protected Over Temperature Protection: 150 +/- 5¡ãF DC Output Short Protection: Yes DC Output Over Current Protection: 72 amps DC Output Over Voltage Protection: TVS Diode Unit Weight: 2.0 lbs. Unit Size L x W x H: 5.91 x 3.39 x 2.2 inches Shipping Weight: 2 lbs. See More Details
